       # CISCO SYSTEMS, INC.

          ATM PCI ADAPTER (VER. 1)

          Card Type              Network Interface Card
          NIC Type               Ethernet
          Maximum Onboard Memory Unidentified
          Boot ROM               Unidentified
          Network Transfer Rate  10KBPS
          Topology               Ring, Peer-Peer
          Wiring Type            Fiber optic cable
          Data Bus               32-bit PCI

 (IMG) IMG 1


          +------------------------------------------------------------+
          |                        CONNECTIONS                         |
          |------------------------------------------------------------|
          |           Function            |           Label            |
          |-------------------------------+----------------------------|
          | Fiber optic connector - SC    |            CN1             |
          +------------------------------------------------------------+

          +------------------------------------------------------------+
          |                     DIAGNOSTIC LED(S)                      |
          |------------------------------------------------------------|
          |   Color    |  Status  |             Condition              |
          |------------+----------+------------------------------------|
          |   Green    |    On    |       Data is being received       |
          |------------+----------+------------------------------------|
          |   Green    |   Off    |     Data is not being received     |
          |------------+----------+------------------------------------|
          |   Yellow   |    On    |     Network connection is good     |
          |------------+----------+------------------------------------|
          |   Yellow   |   Off    |    Network connection is broken    |
          |------------------------------------------------------------|
          | Note: Exact orientation of Green and Yellow LEDs is        |
          | unidentified.                                              |
          +------------------------------------------------------------+
